Tiny PXE Server-1.0.0.23 – Installing System Through Network PXE

Today we are sharing the PXE network installation operating system. I think it’s very practical. Let me throw some thoughts at it. Do you guys have any good techniques you can share. The software used is Tiny PXE Server-1.0.0.17. Download it by yourself from:

Download link: http://reboot.pro/files/file/303-tiny-pxe-server/

My virtual machine is VMware Workstation. The first step is to copy the iso file of the win7 system to the PXESERVER\netboot\ISO directory. Double-click the file iso.bat, green cmd box pops up, select iso1 Enter, press any key to continue our look at open cmd, ipconfig to see the machine ip, local ipv4 is 192.168.1.188, open the PXE Server, the default settings . Click the Online button in the upper left corner, and his Server automatically starts. I test it with a virtual machine here, start the virtual machine, he will automatically obtain the boot from network card service through DHCP, and then it will be the familiar installation screen, this is no need to demonstrate. Forget it, let’s continue the demonstration, from beginning to end! Wait for the loading to complete, click Next -> Install now -> I accept the next step -> Custom

Double-click to select the iso.bat file, a green cmd dialog box pops up, select iso1 and press Enter, press any key to continue

We are opening cmd to check, ipconfig to check the local ip, the local ipv4 is 192.168.1.188, open the PXE Server, and the default settings are fine.

Click the Online button in the upper left corner, and his Server automatically starts.

I test with a virtual machine here, start the virtual machine, he will automatically DHCP to obtain the boot from network card service, and then it is the familiar installation screen

Wait for the loading to complete, click Next -> Install now -> I accept the next step -> Customize

My new hard disk is going to be divided into 2 zones, one zone on the c drive, and the remaining disk size is given to the d drive. Create a new partition on the c drive. Choose the size 31440MB=32.6GB, (1024MB=1GB), and select the allocated space. , Create a new disk, and give the d disk the rest.

Click Next -> Then make a cup of tea and wait for the system to be installed. At this point the end of the tutorial
